ViewSonic introduces newest Projector with High Brightness DLP, the Pro8520HD (Specifications, Features, Images)
The ViewSonic Pro8520HD is a high brightness, Full HD 1080p projector ideal for use in any large venue installation—even in rooms with high ambient light.Built with BrilliantColor technology, this projector produces vibrant colors, while 5000 ANSI lumens and 1080p (1920×1080) Hi-Def resolution deliver stunning, razor-sharp images anywhere from auditoriums, to lecture halls, and boardrooms. With a 1.5x optical zoom lens and a multitude of connectivity options such as dual HDMI, wired and wireless LAN display, USB display, and PC-less JPG slideshows, the Pro8520HD provides maximum installation flexibility for a variety of uses.Equipped with Crestron LAN controller, the Pro8520HD makes it easy for IT admin to remotely control and manage multiple projectors from their workstations. A filter-less design and extended lamp lifeprovide for easy maintenance and alow total cost of ownership (TCO). The Pro8520HD projector offers excellent performance forlarge installations and commercial applications.
Key Specs/Features:
- 5000 ANSI lumens project bright, clear images in any large venue
- Full HD 1080p delivers stunning picture quality
- BrilliantColor technology provides exceptional, true-to-life colors
- Pixelworks high-performance 10-bit video processor for enhanced video quality
- Dual HDMI for true digital picture clarity
- Centralized remote LAN control & monitoring with Crestron for easy management
- Presentation made easy with advanced display options – Wireless & wired LAN display, Plug ‘n play USB display, PC-less JPG slideshows
- Advanced multi-segment color wheel design, 1.5x optical zoom lens, auto source detection & integrated 20w speakers
- Automatic vertical keystone correction for quick and easy image setup
- Virtually maintenance-free with a filter-less design
- Long-lasting, reliable picture quality & superior color performance
- Environmentally friendly Eco-mode saves money and power
- Industry-leading warranty: 3-year limited warranty on parts and labor, 1 year on lamp, and free first year Express Exchange service
| DISPLAY | |
| Type | 0.65″ Digital Micromirror Device (DLP™) |
| Resolution | Full HD 1920×1080 (native) |
| Lens | 1.5x manual optical zoom / manual optical focus |
| Zoom Factor | N/A |
| Keystone | Auto vertical digital keystone correction (+/- 20º) |
| Display Size | 30 – 300 in. / 0.76 – 7.6 m (diagonal) |
| Throw Distance | 3.0 – 30.9 ft. / 0.9 – 9.4 m |
| Throw Ratio | 1.41~2.14:1 |
| Lamp Type | 350 watt |
| Lamp Life (normal/eco-mode) | 2500 / 3000 hours* |
| Brightness | 5000 Lumens |
| Contrast Ratio | 8,000:1 (DCR) |
| Aspect Ratio | 16:9 (native) |
| Color Wheel | 5-seg RGBYW / 7200rpm |
| Color Depth | 30 bits, 1.07B Color (10+10+10) |
| Color Gamut | N/A |
| INPUT SIGNAL | |
| Computer and Video | NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, |
| M, N, 60), SECAM (B, D, G, K, K1, L), SD 480i | |
| and 576i, ED 480p and 576p, HD 720p, 1080i, | |
| 1080p | |
| Frequency | Fh: 31–91KHz, Fv: 48–85Hz |
| COMPATIBILITY | |
| PC | VGA to 1920×1080 |
| Mac® | Up to 1920×1080 (may require MAC adaptor) |
| CONNECTOR | |
| Audio Input | 3.5mm mini jack (x2), RCA (L/R) |
| Audio Out | 3.5mm mini jack |
| RGB Input | 15-pin mini D-sub (x2) |
| Composite Input | RCA jack |
| S-Video Input | 4-pin mini-DIN |
| Component | RCA (x3), 15-pin mini D-sub (x2, shared with RGB) |
| RGB Output | 15-pin mini D-sub |
| Control | RS-232 (DB-9) |
| Digital | HDMI (x2) |
| Network | RJ-45 |
| USB | Type A (flash drive / wireless adapter) Type B |
| (mouse control / service) Mini B (display) | |
| Mic-In | 3.5mm mini jack |
| Screen Trigger | N/A |
| Card Reader | N/A |
| AUDIO | |
| Speakers | 10-watt (x2) |
| Amplifier | N/A |
| POWER | |
| Voltage | 100~240VAC (Auto Switching), 50/60Hz (universal) |
| Consumption | 450w (max) / <0.5w (standby mode) |
| CONTROLS | |
| Basic | Power, keystone/arrow keys, left, menu/exit, right, |
| enter, source | |
| OSD | Picture, Computer Image, Setting, Option, |
| Network (See user guide for full OSD functionality) | |
| OPERATING CONDITIONS | |
| Temperature | 32ºF–104ºF (0ºC–40ºC) |
| Humidity | 10%–90% (non-condensing) |
| Altitude | 0~6,000 ft (1,800m), operational up to 10,000 ft |
| (3048m) | |
| NOISE LEVEL | |
| Normal | 34dB |
| Eco-Mode | 32dB |
| DIMENSIONS (WxHxD) | |
| Physical | 13.1 x 4.8 x 10.4 in. / 333 x 122 x 263 mm |
| Packaging | 16.3 x 14.8 x 7.5 in. / 415 x 377 x 190 mm |
| WEIGHT | |
| Net | 8.5 lb. / 3.9 kg |
| Gross | 11.8 lb. / 5.4 kg |
| LANGUAGE | N/A |
| Regulations | CB, UL/cUL, FCC-B (including ICES-004), |
| CE, TUV-S (Argentina), NOM, GOST-R, | |
| UKrSEPRO, PSB, C-Tick, KC, CCC, CECP, | |
| WEEE, RoHS, SVHC, Hygienic | |
| PACKAGE CONTENTS | Pro8520HD projector, power cable, VGA cable, |
| HDMI cable, laser remote control with batteries, | |
| Warranty | 3-year limited warranty on parts and labor, 1-year |
| limited warranty on lamp, 1st year free Express | |
| Exchange® service |
